35KV Cast Resin Transformer

35KV cast resin transformer

Application
Engineering Case of 35KV Cast Resin Transformer
Yangquan Coal Industry Group
Field Operation Data
Project Requirements for Parameters
Installation Site First Mine Yangpo Weir
Installation Date 2014.8
Operation Time 21 months
Rated Voltage 35/6.3kV
Number of High-voltage Phases Three-phase
Number of Low-voltage Phases Three-phase
Rated Capacity kVA 2000
High-voltage Tapping Scope % ±2×2.5
Rated Current A 33/183.3
Rated Frequency Hz 50
Coupling Group Yd11
No-load Loss W 4230
Load Loss W Level F（120℃） 18200
Total Loss W Level F（120℃） 22430
No-load Current % 0.75
Short-circuit Impedance % 7.2
Noise Level dB 55
Cooling Mode ANAF
Voltage Regulating Mode No excitation voltage adjustment
